| Tekniske spesifikasjoner | | |---------------------------|----------------------------------| |Keyboard|Keyboard61 keys (with velocity) |Keyboard Modes|Whole Dual (volume balance adjustable)///Split(split point, volume balance adjustable)///2-manual/3-manual mode (when using sold separately MIDI keyboard) |Sound Generator|Virtual Tone Wheel Organ///SuperNATURAL Synth///PCM Synth///*GM2 compatible sounds are included. |Maximum Polyphony|128 voices |Parts|Organ (3 parts)///Piano (2 parts)///Synthesizer (2parts)///Drum (1 part)///GM2 (16 parts)Sounds245 sounds |Registrations|100 (4 x 25 banks) |Effects (7 systems always on / global control)|Overdrive///Tone///Compressor///Multi-effects: 20 types///Delay: 6 types///Reverb: 6 types///Rotary: 3 types |Playable File Format|SMF File: Format 0, 1///Audio File: WAV,AIFF,MP3 |Recording Format|SMF File: Format 0///Audio File: WAV (44.1 kHz, 16-bit linear, stereo) |Recording Time|20 seconds (stereo) |Recording/Loadable File Format|Audio File: WAV (44.1 kHz, 16-bit linear, stereo) |Rhythm Patterns|52 |Controller|Virtual Tone Wheel organ: Harmonic bar x 10///Synthesizer controller: Slider x 5///D-BEAM controller///Pitch bend/Modulation lever///Effects knob x 6 (global control) |Display|Graphic LCD 128 x 64 dots |External Memory|USB Flash Memory |Connectors|Output (L/MONO, R) jacks: 1/4-inch phone type///PHONES jack: Stereo 1/4-inch phone type///EXT INPUT jack: Stereo miniature phone type///DAMPER jack: TRS 1/4-inch phone type///EXPRESSION PEDAL jack: TRS 1/4-inch phone type///MIDI (IN, OUT) connectors///PK IN connector: 8-pin DIN type///USB COMPUTER port: USB Type B (supports USB MIDI)///USB MEMORY port: USB Type A///DC IN jack |Power Supply|AC adaptor///Rechargeable Ni-MH battery (AA, HR6) x 8 |Current Draw|600 mA |Expected battery life under continuous use|Rechargeable Ni-MH battery: Approx. 5 hours (approx. 3 hours if USB flash drive is connected)///These figures will vary depending on the specifications of the batteries and the actual conditions of use///* Carbon-zinc batteries and alkaline batteries cannot be used |Accessories|Owner’s Manual///Leaflet using the unit safely///AC adaptor///Power cord///USB memory protector |Options (sold separately)|Keyboard stand : KS-11Z, KS-13///Damper pedal DP series///Expression pedal EV series///Pedalboard: PK-9///USB Flash Memory (*)///* Use a commercially available USB flash drive or a USB flash drive sold by Roland. However, we cannot guarantee that all commercially available USB flash drives will work with this unit. |Size and Weight|Width1,008 mm 39-11/16 inches///Depth300 mm11-13/16 inches///Height106 mm 4-3/16 inches///Weight (excluding AC adaptor)5.5 kg12 lbs 3 oz
