| Tekniske spesifikasjoner | | |---------------------------|----------------------------------| |Sound Generator|ZEN-Core |Tones|1,154 tones/// 74 Drum kits///Sound packs and Wave Expansion from Roland Cloud are available |Effects|Tone MFX: 2 systems, 93 types///Total MFX: 1 system, 15 types///Reverb: 1 system, 4 types |Keyboard|61 keys (Box-shape Keys with velocity) |Touch Sensitivity|Key Touch: 9 types, fixed touch |Speaker|Speaker: 5 cm (2 inches) x 2 (with speaker box)///Passive Radiator x 2 |Bluetooth|Bluetooth Ver 5.0///Profile: A2DP (Audio), GATT (MIDI over Bluetooth Low Energy)///CODEC: SBC (Supports SCMS-T content protection) |Style|Preset: 203 styles///Z-Style packs from Roland Cloud are available |Functions|Start, Stop, Intro, Ending, Sync Start, Variation1, Variation2, Variation3, Variation4, Part Mute |Chord Sequencer|Preset Chord Pattern: 304 types |User Scene|Scene: 256///* Import / export possible |Playable Software|Proprietary MIDI format (99 songs, Approx. 70,000 notes memory per song)///Audio File (WAV: 44.1 kHz, 16-bit linear format, MP3: 44.1 kHz, 64--320 kbps, requires USB flash drive) |Recordable Software|Proprietary MIDI format (99 songs, Approx. 70,000 notes memory per song)///Audio File (WAV: 44.1 kHz, 16-bit linear format, requires USB flash drive) |Master Tuning|415.3--466.2 Hz (Adjustable in increments of 0.1 Hz) |Mic Effects|Auto Harmony (9 types)///Voice Transformer (Octave: -1--+1, Formant: -12--+12 semitones)///Compressor (Type: Soft, Normal, Hard)///Noise Suppressor (Threshold: -96--0 dB) |Convenient Functions|Metronome (Adjustable Tempo/Beat/Down beat/Pattern/Volume/Tone)///Transpose (Keyboard/Style: in semitones)///Octave Shift///Dual///Split (Split point adjustable)///Center Cancel///Arpeggiator///Auto Off |Display|Graphic LCD 128 x 64 dots |Control|Master Volume slider///Pitch Bend Wheel |Connectors|DC In jack///Hold pedal jack (Capable of continuous detection when optional pedal connected)///Control pedal jack (Capable of continuous detection when optional pedal connected)///Input Stereo jack: Stereo miniature phone type///Output (L/Mono, R) jacks: 1/4-inch phone type///Mic Input jack: 1/4-inch phone type///USB COMPUTER port: USB Type-C® (Class Compliant for Audio and MIDI)///USB MEMORY port: USB A (Mass Storage)///EXT DEVICE port: USB A (Roland Cloud Connect WC-1)///Phones jack: Stereo miniature phone type |Power Supply|AC adaptor or Alkaline battery (AA, LR6) / Rechargeable Ni-MH battery (AA, HR6) x 8///* Carbon-zinc batteries cannot be used. |Power Consumption|9 W (When using the included AC adaptor) |Battery Life for Continuous Use|Rechargeable Ni-MH batteries (AA, HR6): Approximately 6 hours (When using batteries having a capacity of 1,900 mAh.)///Alkaline batteries (AA, LR6): Approximately 5 hours///*This figure will vary depending on the actual conditions of use. |Accessories|Quick Start///Leaflet "USING THE UNIT SAFELY"///AC Adaptor///Power Cord |Option (Sold separately)|Dedicated music rest: MRGKS3/5///Keyboard stand: KS-11Z, KS-13, KS-20X///Damper pedal: DP series///Expression pedal: EV-5///Wireless adapter: WC-1 |Width|950 mm,37-7/16 inches |Depth|Detached music rest:286 mm,11-5/16 inches///With music rest:395 mm,15-9/16 inches |Height|Detached music rest:87 mm,3-7/16 inches///With music rest:245 mm,9-11/16 |Weight|4.9 kg, 10 lbs 13 oz///5.5 kg, 12 lbs 3 oz (GO:KEYS 5 with music rest)
